M14BCX-BOTTLE

Active

3M (TC)

CONN SPLICE 14-16AWG CRIMP 100PC

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M14BCX-BOTTLE

Insulation	Non-Insulated
Number of Wire Entries	2
Terminal Type	Butt Splice, Inline, Individual Openings
Termination	Crimp

M14 Series

Part	Width - Outer Edges [y]	Width - Outer Edges [y]	Stud/Tab Size	Features	Length - Ring Center to Termination [x]	Length - Ring Center to Termination [x]	Contact Material	Termination	Mounting Type	Length - Overall [x]	Length - Overall [x]	Insulation	Terminal Type	Contact Finish	Stud/Tab Size	Length - Ring Center to Termination	Length - Ring Center to Termination	Width - Outer Edges	Width - Outer Edges	Length - Termination	Length - Termination [x]	Number of Wire Entries	Thickness	Thickness
3M (TC) M14-6FLK	0.25 "	6.35 mm	6 Stud	Brazed Seam	0.25 in	6.35 mm	Copper ETP	Crimp	Free Hanging (In-Line)	17.27 mm	0.68 in	Non-Insulated	Snap Spring	Tin
3M (TC) M14-8FBX-BOTTLE				Brazed Seam	0.25 in	6.35 mm	Copper ETP	Crimp	Free Hanging (In-Line)	16.5 mm	0.65 "	Non-Insulated	Standard	Tin	8 Stud
3M (TC) M14-6FBX-BOTTLE			6 Stud	Brazed Seam	0.25 in	6.35 mm	Copper ETP	Crimp	Free Hanging (In-Line)	16.5 mm	0.65 "	Non-Insulated	Standard	Tin
3M (TC) M14-8FX-BOTTLE				Brazed Seam			Copper ETP	Crimp	Free Hanging (In-Line)	17.78 mm	0.7 in	Non-Insulated	Standard	Tin	8 Stud	0.29 in	7.37 mm	8.64 mm	0.34 in	6.35 mm	0.25 "
3M (TC) M14BCX-BOTTLE								Crimp				Non-Insulated	Butt Splice Individual Openings Inline									2
3M (TC) M14-6R/SK	0.25 "	6.35 mm	6 Stud	Brazed Seam				Crimp	Free Hanging (In-Line)	15.24 mm	0.6 in	Non-Insulated	Circular										0.03 in	0.76 mm
3M (TC) M14-8R/LX-BOTTLE	0.31 in			Brazed Seam			Copper ETP	Crimp	Free Hanging (In-Line)	18.8 mm	0.74 in	Non-Insulated	Circular	Tin	8 Stud			7.87 mm					0.03 in	0.76 mm
3M (TC) M14-6FBK			6 Stud	Brazed Seam	0.25 in	6.35 mm	Copper ETP	Crimp	Free Hanging (In-Line)	16.5 mm	0.65 "	Non-Insulated	Standard	Tin
3M (TC) M14-6R/SX	0.25 "	6.35 mm	6 Stud	Brazed Seam				Crimp	Free Hanging (In-Line)	15.24 mm	0.6 in	Non-Insulated	Circular										0.03 in	0.76 mm
3M (TC) M14-8FBK				Brazed Seam	0.25 in	6.35 mm	Copper ETP	Crimp	Free Hanging (In-Line)	16.5 mm	0.65 "	Non-Insulated	Standard	Tin	8 Stud
