BT730-SC
ActiveEzurio LLC
BLUETOOTH V2.0 CLASS I USB 1MBPS SMD MODULE EACH
Deep-Dive with AI
Search across all available documentation for this part.
BT730-SC
ActiveEzurio LLC
BLUETOOTH V2.0 CLASS I USB 1MBPS SMD MODULE EACH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BT730-SC |
|---|---|
| Antenna Type | Antenna Not Included, U.FL |
| Current - Receiving | 35 mA |
| Current - Transmitting | 35 mA |
| Data Rate | 2.1 Mbps |
| Frequency | 2.4 GHz |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Power - Output | 18 dBm |
| Protocol | Bluetooth v2.0, Class 1 |
| RF Family/Standard | Bluetooth |
| Sensitivity | -87 dBm |
| Serial Interfaces | UART |
| Utilized IC / Part | BlueCore4 |
| Voltage - Supply [Max] | 5 V |
| Voltage - Supply [Min] | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 30.08 | |
| 50 | $ 28.30 | |||
| 100 | $ 27.41 | |||
Description
General part information
BT730 Series
Bluetooth Bluetooth v2.0, Class 1 Transceiver Module 2.4GHz Antenna Not Included, U.FL Surface Mount
