1000A 0101000

Active

Belden Inc.

CABLE 2COND 16AWG BLK SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 16AWG BLK SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	1000A 0101000

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Constantan, Iron
Conductor Strand	Solid
Features	Rip Cord, Drain Wire
Jacket (Insulation) Diameter [diameter]	0.264 in
Jacket (Insulation) Diameter [diameter]	6.71 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.94 mm
Jacket (Insulation) Thickness	0.037 in
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-30 ░C
Ratings	UL Style 2464
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Thermocouple
Wire Gauge	16 AWG

Part	Shield Coverage	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Number of Conductors	Jacket Color	Features	Wire Gauge	Conductor Insulation	Conductor Strand	Usage	Jacket (Insulation) Material	Shield Type	Shield Material	Ratings	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Length	Length	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]
Belden Inc. 1000A 0101000	100 %	-30 ░C	105 ░C	Multi-Conductor	2	Black	Drain Wire Rip Cord	16 AWG	Poly-Vinyl Chloride (PVC)	Solid	Thermocouple	Poly-Vinyl Chloride (PVC)	Foil	Aluminum	UL Style 2464	0.94 mm	0.037 in	Constantan Iron	1000 ft	304.8 m	0.264 in	6.71 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 2.45

General part information

2 (1 Pair) Conductor Multi-Conductor Cable Black 16 AWG Foil 1000.0' (304.8m)
