AMI-M31NC-1-3-D

Active

Altran Magnetics, LLC

LINE FILTER 3A CHASSIS MOUNT

Search across all available documentation for this part.

Active

Altran Magnetics, LLC

LINE FILTER 3A CHASSIS MOUNT

Technical Specifications

Parameters and characteristics for this part

Part	Applications	Voltage - Rated AC (Phase to Phase)	Operating Temperature [Min]	Operating Temperature [Max]	Configuration	Filter Type	Current	Mounting Type	Frequency - Operating [Max]	Frequency - Operating [Min]	Termination Style	Inductance
Altran Magnetics, LLC AMI-M31NB-10-110-E	General Purpose	480 V	-10 °C	40 °C	Single Stage	Three Phase (Wye)	110 A	Chassis Mount	60 Hz	50 Hz
Altran Magnetics, LLC AMI-M31NC-1-3-D	General Purpose		-10 °C	40 °C	Single Stage	Three Phase (Wye)	3 A	Chassis Mount	60 Hz	50 Hz	Quick Connect	1 mH
Altran Magnetics, LLC AMI-M31NC-1-20-D	General Purpose		-10 °C	40 °C	Single Stage	Three Phase (Wye)	20 A	Chassis Mount	60 Hz	50 Hz	Quick Connect

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Three Phase (Wye) EMC/EMI Line Filter 3 A 50/60Hz Single Stage Quick Connect

Technical documentation and resources

No documents available
