1-1393277-9
ActiveTE Connectivity Potter & Brumfield Relays
RELAY AUTOMOTIVE SPST 40A 24V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1-1393277-9
ActiveTE Connectivity Potter & Brumfield Relays
RELAY AUTOMOTIVE SPST 40A 24V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1-1393277-9 |
|---|---|
| Coil Current | 66.7 mA |
| Coil Power | 1.6 W |
| Coil Resistance | 362 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 24 VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Contact Rating (Current) | 40 A |
| Features | Sealed - Fully |
| Mounting Type | Through Hole |
| Must Operate Voltage | 14.1 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 5 ms |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Release Time | 3 ms |
| Termination Style | PC Pin |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 7.64 | |
| 10 | $ 7.16 | |||
| 525 | $ 4.78 | |||
| 1050 | $ 4.46 | |||
Description
General part information
1393277 Series
RELAY AUTOMOTIVE SPST 40A 24V
