SGD 35-M-420
ActiveLascar Electronics
3.5" PROG 4-20MA PROCESS METER
Deep-Dive with AI
Search across all available documentation for this part.
SGD 35-M-420
ActiveLascar Electronics
3.5" PROG 4-20MA PROCESS METER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SGD 35-M-420 |
|---|---|
| Display Type | TFT - Color (Touch) |
| Measuring Type | Process |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | 0 °C |
| Panel Cutout Dimensions [x] | 92 mm |
| Panel Cutout Dimensions [y] | 75 mm |
| Termination Style | Screw Terminal |
| Type | Process Meter |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 4 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 196.49 | |
Description
General part information
SGD 35 Series
Process Meter TFT - Color (Touch) Display Panel Mount
