ZUW152412-G
ActiveCosel USA, Inc.
DC DC CONVERTER +/-12V 24V 16W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ZUW152412-G
ActiveCosel USA, Inc.
DC DC CONVERTER +/-12V 24V 16W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ZUW152412-G |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 650 mA |
| Current - Output (Max) | 650 mA |
| Efficiency | 83 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 71 °C |
| Operating Temperature [Min] | -20 °C |
| Package / Case | 7-DIP Module |
| Power (Watts) | 16 W |
| Size / Dimension [x] | 1.97 " |
| Size / Dimension [x] | 50 mm |
| Size / Dimension [y] | 1.77 " |
| Size / Dimension [y] | 45 mm |
| Size / Dimension [z] | 0.33 in |
| Size / Dimension [z] | 8.5 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 500 V |
| Voltage - Output 1 | 12 V |
| Voltage - Output 2 | -12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 71.44 | |
Description
General part information
ZUW152412 Series
Isolated Module DC DC Converter 2 Output 12V -12V 650mA, 650mA 18V - 36V Input
