APC-12738P
ActiveEuropean Thermodynamics Ltd
TE CYCLING, 30X30X3.3MM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
APC-12738P
ActiveEuropean Thermodynamics Ltd
TE CYCLING, 30X30X3.3MM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | APC-12738P |
|---|---|
| Current - Max [Max] | 3.8 A |
| Delta Tmax @ Th | 66 °C |
| Features | Lead Wires |
| Height [z] | 3.3 mm |
| Number of Stages | 1 |
| Operating Temperature | 194 °F |
| Qmax @ Th | 36 W |
| Size / Dimension [x] | 34 mm |
| Size / Dimension [y] | 30 mm |
| Voltage - Max [Max] | 14.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 25.71 | |
| 5 | $ 24.16 | |||
| 10 | $ 23.53 | |||
| 25 | $ 22.71 | |||
| 50 | $ 22.11 | |||
| 100 | $ 21.53 | |||
Description
General part information
APC-12738 Series
Peltier Module 36.0W @ 27°C 3.8 A 90°C
