PI2127-01-LGIZ

Obsolete

Vicor Corporation

IC OR CTRLR N+1 17LGA

Search across all available documentation for this part.

Obsolete

Vicor Corporation

IC OR CTRLR N+1 17LGA

Technical Specifications

Parameters and characteristics for this part

Specification	PI2127-01-LGIZ

Applications	Telecom/Datacom Systems, N+1 Power Supplies
Current - Output (Max) [Max]	12 A
Current - Supply	1.5 mA
Delay Time - OFF	80 ns
FET Type	N-Channel
Internal Switch(s)	True
Mounting Type	Surface Mount
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Package / Case	17-LGA
Ratio - Input:Output [custom]	N:1
Supplier Device Package	17-LGA (7x8)
Type	N+1 ORing Controller
Voltage - Supply [Max]	10.5 V
Voltage - Supply [Min]	8.5 V

Part	Supplied Contents	Embedded	Function	Contents	Type	Utilized IC / Part	Delay Time - OFF	Mounting Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Current - Supply	FET Type	Applications	Ratio - Input:Output [custom]	Current - Output (Max) [Max]	Supplier Device Package	Package / Case	Internal Switch(s)
Vicor Corporation PI2127-EVAL1	Board(s)		ORing Controller / Load Share	Board(s)	Power Management	PI2127
Vicor Corporation PI2127-01-LGIZ					N+1 ORing Controller		80 ns	Surface Mount	8.5 V	10.5 V	125 °C	-40 °C	1.5 mA	N-Channel	N+1 Power Supplies Telecom/Datacom Systems	N:1	12 A	17-LGA (7x8)	17-LGA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

OR Controller N+1 ORing Controller N-Channel N:1 17-LGA (7x8)
