SM730K12L
ActiveANYSOLAR Ltd
MONOCRYST SOLAR CELL 189MW 8.29V
Deep-Dive with AI
Search across all available documentation for this part.
SM730K12L
ActiveANYSOLAR Ltd
MONOCRYST SOLAR CELL 189MW 8.29V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SM730K12L |
|---|---|
| Current - Short Circuit (Isc) | 30 mA |
| Current @ Pmpp | 28.2 mA |
| Operating Temperature [Max] | 90 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Cells |
| Power (Watts) - Max [Max] | 189 mW |
| Size / Dimension [x] | 1.299 in |
| Size / Dimension [x] | 33 mm |
| Size / Dimension [y] | 1.26 in |
| Size / Dimension [y] | 32 mm |
| Size / Dimension [z] | 1.8 mm |
| Size / Dimension [z] | 0.071 in |
| Type | Monocrystalline |
| Voltage - Open Circuit | 8.29 V |
| Voltage @ Pmpp | 6.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 4.96 | |
| 25 | $ 4.20 | |||
Description
General part information
SM730 Series
Monocrystalline Solar Cell 189 mW 8.29 V
Documents
Technical documentation and resources
No documents available
