PV275K3225T
ActiveStackpole Electronics Inc
VAR MOV 275VAC/350VDC 400A 430V 3225 SMD T/R
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PV275K3225T
ActiveStackpole Electronics Inc
VAR MOV 275VAC/350VDC 400A 430V 3225 SMD T/R
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PV275K3225T |
|---|---|
| Capacitance @ Frequency | 75 pF |
| Current - Surge | 400 A |
| Energy | 13 J |
| Maximum AC Volts [Max] | 275 V |
| Maximum DC Volts [Max] | 350 V |
| Mounting Type | Surface Mount, MLCV |
| Number of Circuits | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 2-SMD, J-Lead |
| Varistor Voltage (Max) [Max] | 473 V |
| Varistor Voltage (Min) [Min] | 387 V |
| Varistor Voltage (Typ) | 430 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.90 | |
| 10 | $ 0.79 | |||
| 25 | $ 0.75 | |||
| 100 | $ 0.61 | |||
| 250 | $ 0.56 | |||
| 500 | $ 0.48 | |||
| Digi-Reel® | 1 | $ 0.90 | ||
| 10 | $ 0.79 | |||
| 25 | $ 0.75 | |||
| 100 | $ 0.61 | |||
| 250 | $ 0.56 | |||
| 500 | $ 0.48 | |||
| Tape & Reel (TR) | 1000 | $ 0.38 | ||
| 2000 | $ 0.35 | |||
| 5000 | $ 0.32 | |||
| 10000 | $ 0.31 | |||
| 25000 | $ 0.30 | |||
Description
General part information
PV275 Series
430 V 400 A Varistor 1 Circuit Surface Mount, MLCV 2-SMD, J-Lead
