RBE05DHFR

Active

Sullins Connector Solutions

CONN EDGE DUAL FMALE 10POS 0.039

Deep-Dive with AI

Search across all available documentation for this part.

RBE05DHFR

Active

Sullins Connector Solutions

CONN EDGE DUAL FMALE 10POS 0.039

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	RBE05DHFR

Card Thickness	0.062 in
Card Thickness	1.57 mm
Card Type	Non Specified - Dual Edge
Color	Black
Contact Finish	Gold
Contact Finish Thickness	10 Áin
Contact Finish Thickness	0.25 Ám
Contact Material	Phosphor Bronze
Contact Type	Hairpin Bellows
Gender	Female
Material - Insulation	Polyphenylene Sulfide (PPS)
Mounting Type	Surface Mount
Number of Positions	10
Number of Positions/Bay/Row [custom]	5
Number of Rows	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-65 ░C
Pitch [x]	0.039 in
Pitch [x]	1 mm
Read Out	Dual
Termination	Solder

RBE05 Series

Part	Read Out	Gender	Number of Positions/Bay/Row [custom]	Card Type	Contact Finish	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Card Thickness	Card Thickness	Number of Rows	Contact Finish Thickness	Contact Finish Thickness	Contact Type	Pitch [x]	Pitch [x]	Contact Material	Number of Positions	Termination	Material - Insulation	Color	Flange Feature	Flange Feature	Flange Feature	Features	Flange Feature [diameter]	Flange Feature [diameter]
Sullins Connector Solutions RBE05DHHN	Dual	Female	5	Non Specified - Dual Edge	Gold	Through Hole	125 °C	-65 ░C	0.062 in	1.57 mm	2	10 Áin	0.25 Ám	Hairpin Bellows	0.039 in	1 mm	Phosphor Bronze	10	Solder Staggered	Polyphenylene Sulfide (PPS)	Black
Sullins Connector Solutions RBE05DHFR	Dual	Female	5	Non Specified - Dual Edge	Gold	Surface Mount	125 °C	-65 ░C	0.062 in	1.57 mm	2	10 Áin	0.25 Ám	Hairpin Bellows	0.039 in	1 mm	Phosphor Bronze	10	Solder	Polyphenylene Sulfide (PPS)	Black
Sullins Connector Solutions RBE05DHHD	Dual	Female	5	Non Specified - Dual Edge	Gold	Through Hole	125 °C	-65 ░C	0.062 in	1.57 mm	2	10 Áin	0.25 Ám	Hairpin Bellows	0.039 in	1 mm	Phosphor Bronze	10	Solder Staggered	Polyphenylene Sulfide (PPS)	Black	Flush Mount Top Opening Unthreaded	0.125 "	3.18 mm
Sullins Connector Solutions RBE05DHRT	Dual	Female	5	Non Specified - Dual Edge	Gold	Board Edge Straddle Mount	125 °C	-65 ░C	0.062 in	1.57 mm	2	10 Áin	0.25 Ám	Hairpin Bellows	0.039 in	1 mm	Phosphor Bronze	10	Solder	Polyphenylene Sulfide (PPS)	Black	4-40 Flush Mount Threaded Insert Top Opening			Card Extender
Sullins Connector Solutions RBE05DHAS	Dual	Female	5	Non Specified - Dual Edge	Gold	Through Hole Right Angle	125 °C	-65 ░C	0.062 in	1.57 mm	2	10 Áin	0.25 Ám	Hairpin Bellows	0.039 in	1 mm	Phosphor Bronze	10	Solder Staggered	Polyphenylene Sulfide (PPS)	Black	Side Mount Opening Unthreaded				0.125 in	3.18 mm
Sullins Connector Solutions RBE05DHFT	Dual	Female	5	Non Specified - Dual Edge	Gold	Surface Mount	125 °C	-65 ░C	0.062 in	1.57 mm	2	10 Áin	0.25 Ám	Hairpin Bellows	0.039 in	1 mm	Phosphor Bronze	10	Solder	Polyphenylene Sulfide (PPS)	Black	4-40 Flush Mount Threaded Insert Top Opening

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 12.87
		10	$ 11.40
		30	$ 10.96
		50	$ 10.53
		100	$ 9.94
		250	$ 9.06
		500	$ 8.48
		1000	$ 7.78

Description

General part information

RBE05 Series

10 Position Female Connector Non Specified - Dual Edge Gold 0.039" (1.00mm) Black

Documents

Technical documentation and resources

No documents available
