PM5-PYD

Active

Bivar Inc.

LED PANEL MOUNT INDICATOR, YELLOW, 48 V, 10 MM, 20 MA, 300 MCD, IP67

Search across all available documentation for this part.

Active

Bivar Inc.

LED PANEL MOUNT INDICATOR, YELLOW, 48 V, 10 MM, 20 MA, 300 MCD, IP67

Technical Specifications

Parameters and characteristics for this part

Specification	PM5-PYD

Ingress Protection	IP67
Lamp Color	Yellow
Lens Color	White
Lens Size [diameter]	9.7 mm
Lens Transparency	Diffused
Millicandela Rating	300 mcd
Panel Cutout Dimensions [custom]	9.91 mm
Panel Cutout Dimensions [custom]	0.39 in
Panel Cutout Shape	Round
Ratings	AC/DC
Type	LED
Viewing Angle	120 °
Voltage [Max]	48 V
Voltage [Min]	8 V
Wavelength - Peak	590 nm

Part	Millicandela Rating	Type	Panel Cutout Dimensions [custom]	Panel Cutout Dimensions [custom]	Lens Transparency	Voltage [Min]	Voltage [Max]	Lamp Color	Wavelength - Peak	Lens Size [diameter]	Ratings	Ingress Protection	Lens Color	Viewing Angle	Panel Cutout Shape
Bivar Inc. PM5-PYD	300 mcd	LED	9.91 mm	0.39 in	Diffused	8 V	48 V	Yellow	590 nm	9.7 mm	AC/DC	IP67	White	120 °	Round

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	100	$ 10.83
Newark	Each	1	$ 11.88

General part information

LED Panel Indicator Yellow Diffused 120° 8V ~ 48V 20mA
