CG-PG11-2-BK

Active

Essentra Access Solutions

CABLE GLAND 5-10MM PG11 POLYAMID

Search across all available documentation for this part.

Active

Essentra Access Solutions

CABLE GLAND 5-10MM PG11 POLYAMID

Technical Specifications

Parameters and characteristics for this part

Specification	CG-PG11-2-BK

Color	Black
Includes	Sealing Gland, Sealing Nut
Ingress Protection	IP68 - Dust Tight, Waterproof
Material	Polyamide (PA), Nylon
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-20 C
Outside Cable Diameter (Max) [Max] [diameter]	0.394 "
Outside Cable Diameter (Max) [Max] [diameter]	10 mm
Outside Cable Diameter (Min) [Min]	5 mm
Outside Cable Diameter (Min) [Min]	0.197 in
Panel Hole Size	0.74 in
Panel Hole Size	18.8 mm
Thread Length	8 mm
Thread Length	0.315 in
Thread Size	PG11
Type	Cable Gland

Part	Ingress Protection	Material	Includes	Type	Color	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Max) [Max] [diameter]	Panel Hole Size	Panel Hole Size	Operating Temperature [Max]	Operating Temperature [Min]	Thread Length	Thread Length	Outside Cable Diameter (Min) [Min]	Outside Cable Diameter (Min) [Min]	Thread Size
Essentra Access Solutions CG-PG11-2-BK	IP68 - Dust Tight Waterproof	Polyamide (PA) Nylon	Sealing Gland Sealing Nut	Cable Gland	Black	0.394 "	10 mm	0.74 in	18.8 mm	100 °C	-20 C	8 mm	0.315 in	5 mm	0.197 in	PG11

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Gland Polyamide (PA), Nylon PG11 Black
