2SD1835S-AA

Active

Sanyo

TRANS NPN 50V 2A 3NP

Search across all available documentation for this part.

Active

Sanyo

TRANS NPN 50V 2A 3NP

Technical Specifications

Parameters and characteristics for this part

Specification	2SD1835S-AA

Current - Collector (Ic) (Max) [Max]	2 A
Current - Collector Cutoff (Max) [Max]	100 nA
DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	100
Frequency - Transition	150 MHz
Mounting Type	Through Hole
Operating Temperature	150 °C
Package / Case	TO-226-3, TO-92-3
Power - Max [Max]	750 mW
Supplier Device Package	3-NP
Transistor Type	NPN
Vce Saturation (Max) @ Ib, Ic [Max]	400 mV
Voltage - Collector Emitter Breakdown (Max) [Max]	50 V

Part	Current - Collector (Ic) (Max) [Max]	Supplier Device Package	Mounting Type	Frequency - Transition	Operating Temperature	Voltage - Collector Emitter Breakdown (Max) [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Current - Collector Cutoff (Max) [Max]	Vce Saturation (Max) @ Ib, Ic [Max]	Package / Case	Power - Max [Max]	Transistor Type
Sanyo 2SD1835S-AA	2 A	3-NP	Through Hole	150 MHz	150 °C	50 V	100	100 nA	400 mV	TO-226-3 TO-92-3	750 mW	NPN

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	2420	$ 0.12

General part information

Bipolar (BJT) Transistor NPN 50 V 2 A 150MHz 750 mW Through Hole 3-NP

Technical documentation and resources

No documents available
