2-1415074-1
ActiveTE Connectivity Potter & Brumfield Relays
RELAY GEN PURPOSE DPDT 8A 230V
Deep-Dive with AI
Search across all available documentation for this part.
2-1415074-1
ActiveTE Connectivity Potter & Brumfield Relays
RELAY GEN PURPOSE DPDT 8A 230V
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 2-1415074-1 |
|---|---|
| Approval Agency | cURus, CQC, VDE, CSA |
| Coil Current | 3.2 mA |
| Coil Insulation | Class F |
| Coil Resistance | 32500 Ohms |
| Coil Type | Non Latching |
| Coil Voltage | 230 VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 8 A |
| Features | Lighted Indicator, Socket Included |
| Load - Max Switching | 3200 VA |
| Mounting Type | DIN Rail |
| Must Operate Voltage | 172.5 VAC |
| Must Release Voltage | 34.5 VAC |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 C |
| Relay Type | General Purpose |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 22.13 | |
| 10 | $ 19.68 | |||
| 100 | $ 16.72 | |||
Description
General part information
1415074 Series
General Purpose Relay DPDT (2 Form C) 230VAC Coil DIN Rail
