FN-PX14P-15

Gelid Solutions LLC

FAN AXL 120X25MM 12VDC RECT CONN

Search across all available documentation for this part.

Gelid Solutions LLC

FAN AXL 120X25MM 12VDC RECT CONN

Technical Specifications

Parameters and characteristics for this part

Specification	FN-PX14P-15

Air Flow	2.26 m³/min
Air Flow	80.7 CFM
Approval Agency	CE
Bearing Type	Hydrodynamic
Current Rating (Amps)	0.2 A
Fan Type	Tubeaxial
Features	PWM Control, Speed Sensor (Tach), Fan Mounts Included
Lifetime @ Temp.	50000 Hrs
Noise	27.8 dB(A)
RPM	1500 RPM
Size / Dimension	Square/Rounded
Size / Dimension [x]	120 mm
Size / Dimension [z]	120 mm
Static Pressure	18.2 Pa
Static Pressure	0.073 in H2O
Termination	4 Position Rectangular Connector
Voltage - Rated	12 VDC
Width [y]	25 mm

Part	Current Rating (Amps)	RPM	Static Pressure	Static Pressure	Voltage - Rated	Width [y]	Lifetime @ Temp.	Noise	Fan Type	Air Flow	Air Flow	Bearing Type	Features	Size / Dimension	Size / Dimension [x]	Size / Dimension [z]	Termination	Approval Agency
Gelid Solutions LLC FN-PX14P-15	0.2 A	1500 RPM	18.2 Pa	0.073 in H2O	12 VDC	25 mm	50000 Hrs	27.8 dB(A)	Tubeaxial	2.26 m³/min	80.7 CFM	Hydrodynamic	Fan Mounts Included PWM Control Speed Sensor (Tach)	Square/Rounded	120 mm	120 mm	4 Position Rectangular Connector	CE
Gelid Solutions LLC FN-PX14-12	0.2 A	1200 RPM	14.7 Pa	0.059 in H2O	12 VDC	25 mm	50000 Hrs	20 dB	Tubeaxial	2.09 m³/min	74.5 CFM	Hydrodynamic	Fan Mounts Included PWM Control Speed Sensor (Tach)		140 mm	140 mm	4 Position Rectangular Connector	CE

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fan Tubeaxial 12VDC Square/Rounded - 120mm L x 120mm H Hydrodynamic 80.7 CFM (2.26m³/min) 4 Position Rectangular Connector
