44540-0010
ObsoleteOmron Electronics Inc-EMC Div
INTERLOCK NON-LOCKING DPST
Deep-Dive with AI
Search across all available documentation for this part.
44540-0010
ObsoleteOmron Electronics Inc-EMC Div
INTERLOCK NON-LOCKING DPST
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 44540-0010 |
|---|---|
| Actuator Type | Panel Disconnect |
| Approval Agency | cULus, CE |
| Circuit | DPST-NO/NC |
| Conduit Thread Size | M16 |
| Current Rating (Amps) | 4 A |
| Holding Force | 612 gf |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -20 C |
| Termination Style | Screw Terminal |
| Type | Non-Locking |
| Voltage Rating | 230 VAC, 24 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
44540 Series
INTERLOCK NON-LOCKING DPST
Documents
Technical documentation and resources
No documents available
