VHS1-S12-S9-SIP

Obsolete

CUI Inc.

MODULE DC-DC 12VIN 1-OUT 9V 0.111A 1W 4-PIN SIP MODULE

Search across all available documentation for this part.

Obsolete

CUI Inc.

MODULE DC-DC 12VIN 1-OUT 9V 0.111A 1W 4-PIN SIP MODULE

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Efficiency	Approval Agency	Features	Number of Outputs	Current - Output (Max) [Max]	Standard Number	Voltage - Output 1	Applications	Voltage - Isolation	Voltage - Input (Max) [Max]	Type	Package / Case	Voltage - Input (Min) [Min]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]
CUI Inc. VHS1-S12-S5-SIP	85 °C	-40 °C	Through Hole	75 %	UL	SCP	1	200 mA	60950-1	5 V	Medical	6000 V	13.2 V	Isolated Module	7-SIP Module 4 Leads	10.8 V
CUI Inc. VHS1-S12-S9-SIP	105 ░C	-40 °C	Through Hole		UL	SCP	1		60950-1	9 V	ITE (Commercial)	6000 V	13.2 V	Isolated Module	7-SIP Module 5 Leads	10.8 V	0.77 in	0.39 "	12.5 mm	0.49 in	19.7 mm	9.8 mm
CUI Inc. VHS1-S12-S12-SIP	85 °C	-40 °C	Through Hole	78 %	UL	SCP	1	84 mA	60950-1	12 V	Medical	6000 V	13.2 V	Isolated Module	7-SIP Module 4 Leads	10.8 V
CUI Inc. VHS1-S12-S15-SIP	85 °C	-40 °C	Through Hole	78 %	UL	SCP	1	67 mA	60950-1	15 V	Medical	6000 V	13.2 V	Isolated Module	7-SIP Module 4 Leads	10.8 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 9V 111mA 10.8V - 13.2V Input

Technical documentation and resources

No documents available
