2292906-1
ActiveTE Connectivity Raychem Cable Protection
AUTOMOTIVE HOUSING, RCPT, 2POS, BLACK ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
2292906-1
ActiveTE Connectivity Raychem Cable Protection
AUTOMOTIVE HOUSING, RCPT, 2POS, BLACK ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 2292906-1 |
|---|---|
| Color | Black |
| Connector Type | Receptacle |
| Contact Termination | Crimp |
| Contact Type | Female Socket |
| Fastening Type | Latch Holder |
| Insulation Material | Liquid Crystal Polymer (LCP) |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Pitch [x] | 2.54 mm |
| Pitch [x] | 0.1 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
enetSEAL+ Series
2 Position Housing, Plug, Cable-to-Cable / Wire-to-Wire, 2.54 mm [.1 in] Centerline, Sealable, Black, Wire & Cable, Signal, enetSEAL+
Documents
Technical documentation and resources
