B689 5643-I BLK/YEL STYLE I

Search across all available documentation for this part.

Active

BRADY

B689 5643-I BLK/YEL STYLE I

Technical Specifications

Parameters and characteristics for this part

Specification	5643-I

Application Specifics	Directionality
Applications	Pipe
Arrangement	Symbol and Text
Color - Background	Yellow
Color - Legend	Black
Features	Water Resistant, Weather Resistant, Humidity Resistant, Chemical Resistant, UV Resistant, Abrasion Resistant
Language	English
Legend (Symbol Only)	Directional Arrow
Legend (Text)	Caustic
Length	9 "
Length	228.6 mm
Location	Outdoor
Material - Body	Plastic
Mounting Type	Snap On
Outside Pipe Diameter (Max) [diameter]	1.5 "
Outside Pipe Diameter (Max) [diameter]	38.1 mm
Outside Pipe Diameter (Min) [Min] [diameter]	2.375 in
Outside Pipe Diameter (Min) [Min] [diameter]	60.33 mm
Print Type	Pre-Printed
Shape	Rectangle
Width [x]	8 in
Width [x]	203.2 mm

Part	Length	Length	Color - Background	Legend (Text)	Arrangement	Shape	Material - Body	Width [x]	Width [x]	Outside Pipe Diameter (Max) [diameter]	Outside Pipe Diameter (Max) [diameter]	Legend (Symbol Only)	Applications	Location	Features	Application Specifics	Mounting Type	Print Type	Outside Pipe Diameter (Min) [Min] [diameter]	Outside Pipe Diameter (Min) [Min] [diameter]	Language	Color - Legend	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Max) [Max] [diameter]	Outside Pipe Diameter (Min) [Min] [diameter]	Width [y]	Width [y]
BRADY 5643-I	9 "	228.6 mm	Yellow	Caustic	Symbol and Text	Rectangle	Plastic	8 in	203.2 mm	1.5 "	38.1 mm	Directional Arrow	Pipe	Outdoor	Abrasion Resistant Chemical Resistant Humidity Resistant UV Resistant Water Resistant Weather Resistant	Directionality	Snap On	Pre-Printed	2.375 in	60.33 mm	English	Black
BRADY 5643-O	8 in	203.2 mm	Yellow	Caustic	Symbol and Text	Rectangle	Plastic					Directional Arrow	Pipe	Outdoor	Abrasion Resistant Chemical Resistant Humidity Resistant UV Resistant Water Resistant Weather Resistant	Directionality	Snap On	Pre-Printed	1.375 in		English	Black	12.7 mm	0.5 "	34.93 mm	127 mm	5 in
