ADC-02PMMS-SS7001

Active

Amphenol LTW

CERES, LARGE SIZE, PLASTIC, 20A, 02 PINS, MALE CONNECTOR, MALE CONTACT, SQUARE, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS COMP

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, LARGE SIZE, PLASTIC, 20A, 02 PINS, MALE CONNECTOR, MALE CONTACT, SQUARE, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS COMP

Technical Specifications

Parameters and characteristics for this part

Specification	ADC-02PMMS-SS7001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	20 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut, Flange
Number of Positions	2
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	D
Shielding	Unshielded
Voltage Rating	250 VAC

Part	Insert Material	Mounting Feature	Current Rating (Amps)	Primary Material	Voltage Rating	Color	Shielding	Material Flammability Rating	Connector Type	Number of Positions	Ingress Protection	Shell Material	Contact Finish - Mating	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Shell Size - Insert	Fastening Type
Amphenol LTW ADC-02PMMS-SS7001	Polyamide (PA) Nylon Glass Filled	Bulkhead - Front Side Nut Flange	20 A	Plastic	250 VAC	Black	Unshielded	UL94 V-0	Male Pins Receptacle	2	IP67 - Dust Tight Waterproof	Glass Filled Nylon Polyamide (PA)	Gold	Keyed	-40 °C	105 ░C	Copper Alloy	D
Amphenol LTW ADC-02PMMS-LC7001	Polyamide (PA) Nylon Glass Filled	Bulkhead - Front Side Nut	20 A	Plastic	250 VAC	Black	Unshielded	UL94 V-0	Male Pins Receptacle	2	IP67 - Dust Tight Waterproof	Glass Filled Nylon Polyamide (PA)	Gold	Keyed	-40 °C	105 ░C	Copper Alloy	D	Bayonet Lock

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Position Circular Connector Receptacle, Male Pins Solder Cup
