ISO5125I-45
ActivePower Integrations
DC/DC CONVERTER 5W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ISO5125I-45
ActivePower Integrations
DC/DC CONVERTER 5W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ISO5125I-45 |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 200 mA |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 5 W |
| Size / Dimension [x] | 4.72 " |
| Size / Dimension [x] | 120 mm |
| Size / Dimension [y] | 1.85 " |
| Size / Dimension [y] | 47 mm |
| Size / Dimension [z] | 1.75 " |
| Size / Dimension [z] | 44.5 mm |
| Type | Open Frame |
| Voltage - Input (Max) [Max] | 15.5 V |
| Voltage - Input (Min) [Min] | 14.5 V |
| Voltage - Isolation | 7.4 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 223.03 | |
| 10 | $ 216.16 | |||
| 40 | $ 200.04 | |||
Description
General part information
ISO5125 Series
Open Frame DC DC Converter 1 Output 200mA 15.5V Input
