DSR75PS48

Obsolete

XP POWER

AC/DC DIN RAIL SUPPLY 48V 77W

Search across all available documentation for this part.

Obsolete

XP POWER

AC/DC DIN RAIL SUPPLY 48V 77W

Technical Specifications

Parameters and characteristics for this part

Specification	DSR75PS48

AC Voltage - Input [Max]	264 VAC
AC Voltage - Input [Min]	85 VAC
Applications	Industrial, ITE (Commercial)
Approval Agency	TUV, CB, cULus, cURus, CE
Current - Output (Max) [Max]	1.6 A
Efficiency	91 %
Features	Adjustable Output, Universal Input
Input Type	AC
Minimum Load Required	False
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-25 °C
Power (Watts)	77 W
Size / Dimension [x]	4.47 in
Size / Dimension [x]	113.5 mm
Size / Dimension [y]	1.26 in
Size / Dimension [y]	32 mm
Size / Dimension [z]	4.88 "
Size / Dimension [z]	124 mm
Standard Number	62368-1
Voltage - Isolation	3000 V
Voltage - Output 1	48 V

Part	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Input Type	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Features	Number of Outputs	Applications	AC Voltage - Input [Min]	AC Voltage - Input [Max]	Standard Number	Voltage - Output 1	Current - Output (Max) [Max]	Minimum Load Required	Approval Agency	Power (Watts)	Efficiency
XP POWER DSR75PS48	-25 °C	70 °C	3000 V	AC	4.47 in	4.88 "	124 mm	113.5 mm	1.26 in	32 mm	Adjustable Output Universal Input	1	Industrial ITE (Commercial)	85 VAC	264 VAC	62368-1	48 V	1.6 A		CB CE cULus cURus TUV	77 W	91 %
XP POWER DSR75PS12	-25 °C	70 °C	3000 V	AC	4.47 in	4.88 "	124 mm	113.5 mm	1.26 in	32 mm	Adjustable Output Universal Input	1	Industrial ITE (Commercial)	85 VAC	264 VAC	62368-1	12 V	6.3 A		CB CE cULus cURus TUV	76 W	88 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

AC/DC DIN RAIL SUPPLY 48V 77W

Technical documentation and resources
