PWC-5E
ActiveAstrodyne TDI
AC/DC CONVERTER 5V 5W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PWC-5E
ActiveAstrodyne TDI
AC/DC CONVERTER 5V 5W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PWC-5E |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus, UL |
| Current - Output (Max) [Max] | 1 A |
| Efficiency | 72 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 1 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 65 °C |
| Operating Temperature [Min] | -25 °C |
| Package / Case | 4-DIP Module |
| Power (Watts) | 5 W |
| Size / Dimension [x] | 50.8 mm |
| Size / Dimension [x] | 2 in |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [y] | 25.4 mm |
| Size / Dimension [z] | 0.6 " |
| Size / Dimension [z] | 15.2 mm |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Output 1 | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 5 | $ 27.39 | |
| 10 | $ 24.90 | |||
| 25 | $ 22.64 | |||
Description
General part information
PWC-5 Series
Enclosed AC DC Converters 1 Output 5V 1A 90 ~ 264 VAC Input
