PAA30B-14C
ActiveTT Electronics/Power Partners Inc.
AC/DC CONVERTER 24V 30W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PAA30B-14C
ActiveTT Electronics/Power Partners Inc.
AC/DC CONVERTER 24V 30W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PAA30B-14C |
|---|---|
| Applications | Household Appliances, ITE (Commercial) |
| Approval Agency | CB, cURus, CE |
| Efficiency | 86 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Power (Watts) | 30 W |
| Size / Dimension [x] | 3.78 " |
| Size / Dimension [x] | 96 mm |
| Size / Dimension [y] | 2.12 in |
| Size / Dimension [y] | 53.9 mm |
| Size / Dimension [z] | 29 mm |
| Size / Dimension [z] | 1.14 " |
| Type | Enclosed |
| Voltage - Input [Max] | 305 VAC, 430 VDC |
| Voltage - Input [Min] | 127 VDC, 90 VAC |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 37.34 | |
| 5 | $ 36.25 | |||
| 10 | $ 35.15 | |||
| 25 | $ 34.05 | |||
| 50 | $ 32.95 | |||
| 100 | $ 31.85 | |||
| 250 | $ 30.75 | |||
Description
General part information
PAA30 Series
Enclosed AC DC Converters 1 Output 24V 90 ~ 305 VAC, 127 ~ 430 VDC Input
