IEU0324D05

Active

XP POWER

DC DC CONVERTER +/-5V 3W

Search across all available documentation for this part.

Active

XP POWER

DC DC CONVERTER +/-5V 3W

Technical Specifications

Parameters and characteristics for this part

Part	Efficiency	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Features	Voltage - Isolation	Mounting Type	Package / Case	Package / Case	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Type	Applications	Standard Number	Voltage - Input (Min) [Min]	Power (Watts)	Voltage - Output 1	Number of Outputs	Current - Output (Max)	Voltage - Output 2	Current - Output (Max)
XP POWER IEU0324S12	87 %	0.55 in	14 mm	0.31 in	8 mm	0.55 in	14 mm	OCP SCP	1.5 kV	Through Hole	8-DIP Module	4 Lead	250 mA	36 V	-40 °C	203 °F	Isolated Module	ITE (Commercial)	62368-1	18 V	3 W	12 V	1
XP POWER IEU0324D05	84 %	0.55 in	14 mm	0.31 in	8 mm	0.55 in	14 mm	OCP SCP	1.5 kV	Through Hole	5 Leads 8-DIP Module			36 V	-40 °C	203 °F	Isolated Module	ITE (Commercial)	62368-1	18 V	3 W	5 V	2	300 mA	-5 V
XP POWER IEU0324D15	87 %	0.55 in	14 mm	0.31 in	8 mm	0.55 in	14 mm	OCP SCP	1.5 kV	Through Hole	5 Leads 8-DIP Module			36 V	-40 °C	203 °F	Isolated Module	ITE (Commercial)	62368-1	18 V	3 W	15 V	2	100 mA	-15 V	100 mA
XP POWER IEU0324S3V3	80 %	0.55 in	14 mm	0.31 in	8 mm	0.55 in	14 mm	OCP SCP	1.5 kV	Through Hole	8-DIP Module	4 Lead	600 mA	36 V	-40 °C	203 °F	Isolated Module	ITE (Commercial)	62368-1	18 V	3 W	3.3 V	1
XP POWER IEU0324S15	87 %	0.55 in	14 mm	0.31 in	8 mm	0.55 in	14 mm	OCP SCP	1.5 kV	Through Hole	8-DIP Module	4 Lead	200 mA	36 V	-40 °C	203 °F	Isolated Module	ITE (Commercial)	62368-1	18 V	3 W	15 V	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 2 Output 5V -5V 300mA, 300mA 18V - 36V Input
