MLV12-54-LAS/92/120

Active

PEPPERL+FUCHS

PHOTOELECTRIC SENSOR, MLV12 SERIES, 12 M, RETROREFLECTIVE, PNP, 10 VDC TO 30 VDC, M12 CONNECTOR

Search across all available documentation for this part.

Active

PEPPERL+FUCHS

PHOTOELECTRIC SENSOR, MLV12 SERIES, 12 M, RETROREFLECTIVE, PNP, 10 VDC TO 30 VDC, M12 CONNECTOR

Technical Specifications

Parameters and characteristics for this part

Specification	MLV12-54-LAS/92/120

Current - Supply	40 mA
Mounting Type	Chassis Mount
Output Configuration	PNP - Dark-ON/Light-ON - Selectable
Package / Case	Module
Sensing Distance	12 m
Sensing Distance	472.44 in
Sensing Light	Infrared
Sensing Method	Retroreflective
Voltage - Supply [Max]	30 VDC
Voltage - Supply [Min]	10 VDC

Part	Sensing Light	Voltage - Supply [Max]	Voltage - Supply [Min]	Output Configuration	Current - Supply	Sensing Method	Package / Case	Mounting Type	Sensing Distance	Sensing Distance	Sensing Object	Ingress Protection	Adjustment Type	Connection Method	Response Time	Sensing Distance [Max]	Sensing Distance [Min]	Sensing Distance [Min]	Sensing Distance [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Light Source
PEPPERL+FUCHS MLV12-54-LAS/92/120	Infrared	30 VDC	10 VDC	PNP - Dark-ON/Light-ON - Selectable	40 mA	Retroreflective	Module	Chassis Mount	12 m	472.44 in
PEPPERL+FUCHS MLV12-54/47/92	Infrared	30 VDC	10 VDC	PNP - Dark-ON/Light-ON - Selectable	40 mA	Retroreflective	Module	Chassis Mount
PEPPERL+FUCHS MLV12-54-G/76B/124/128	Infrared	30 VDC	10 VDC	Dark-On Light-On	55 mA	Retroreflective	Module	Chassis Mount	4.2 m	165.35 in	Glass
PEPPERL+FUCHS MLV12-8-H-250-RT/47/65B/92		30 VDC	10 VDC	PNP - Open Collector Light-ON\Dark-ON		Diffuse						IP67	Adjustable	Connector M12	500 µs	250 mm	20 mm	0.787 "	9.843 "	-40 °C	60 °C	Red LED

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 644.52
		10	$ 623.43
Newark	Each	1	$ 731.09

General part information

Retroreflective Optical Sensor 472.44" (12m) Module
