AM15EW-2412SZ

Active

DComponents

DC DC CONVERTER 12V 15W

Search across all available documentation for this part.

Active

DComponents

DC DC CONVERTER 12V 15W

Technical Specifications

Parameters and characteristics for this part

Part	Applications	Mounting Type	Number of Outputs	Type	Voltage - Output 2	Efficiency	Current - Output (Max)	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Voltage - Input (Min) [Min]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Approval Agency	Power (Watts)	Voltage - Input (Max) [Max]	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Features	Voltage - Output 1	Current - Output (Max) [Max]	Current - Output (Max)	Current - Output (Max)
DComponents AM15E-1224DZ	ITE (Commercial)	Through Hole	2	Isolated Module	-24 V	85 %	310 mA	-24 V	24 V	9 V	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	CE cULus cURus	15 W	18 V	1.5 kV	85 °C	-40 °C
DComponents AM15EW-2412SZ	ITE (Commercial)	Through Hole	1	Isolated Module		85 %				9 V	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	CE cULus cURus	15 W	36 V	1.5 kV	85 °C	-40 °C	5 Leads	6-DIP Module	Remote On/Off	12 V	1.25 A
DComponents AM15E-1215DZ	ITE (Commercial)	Through Hole	2	Isolated Module	-15 V	84 %				9 V	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	CE cURus	15 W	18 V	1.5 kV	85 °C	-40 °C		5-DIP Module		15 V		500 mA	500 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 12V 1.25A 9V - 36V Input
