ZM5202AE-CME3R
Silicon Labs
RF TXRX MOD ISM<1GHZ SMD
Deep-Dive with AI
Search across all available documentation for this part.
ZM5202AE-CME3R
Silicon Labs
RF TXRX MOD ISM<1GHZ SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ZM5202AE-CME3R |
|---|---|
| Current - Receiving | 32 mA |
| Current - Transmitting | 41 mA |
| Data Rate | 100 Kbps |
| Frequency | 868 MHz |
| Memory Size | 128 kB, 16 kB |
| Mounting Type | Surface Mount |
| Package / Case | Module |
| Power - Output | 4 dBm |
| Protocol | Z-Wave® |
| RF Family/Standard | General ISM < 1GHz |
| Sensitivity | -103 dBm |
| Serial Interfaces | SPI, USB, UART |
| Voltage - Supply [Max] | 3.6 V |
| Voltage - Supply [Min] | 2.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 17.51 | |
| 10 | $ 13.72 | |||
| 25 | $ 12.58 | |||
| 100 | $ 11.19 | |||
| 250 | $ 10.45 | |||
| 500 | $ 9.97 | |||
| Digi-Reel® | 1 | $ 17.51 | ||
| 10 | $ 13.72 | |||
| 25 | $ 12.58 | |||
| 100 | $ 11.19 | |||
| 250 | $ 10.45 | |||
| 500 | $ 9.97 | |||
| Tape & Reel (TR) | 1000 | $ 9.56 | ||
Description
General part information
ZM5202 Series
General ISM < 1GHz Z-Wave® Transceiver Module 868MHz Surface Mount
