AEV250-MA

Active

Altran Magnetics, LLC

DC CONTACTOR 500A 12-24VDC AUX

Search across all available documentation for this part.

Active

Altran Magnetics, LLC

DC CONTACTOR 500A 12-24VDC AUX

Technical Specifications

Parameters and characteristics for this part

Specification	AEV250-MA

Coil Current	130 mA
Coil Voltage [Max]	24 VDC
Coil Voltage [Min]	12 VDC
Contact Form	SPST-NO (DM) (1 Form X)
Contact Rating (Current)	500 A
Features	Economizer, Sealed - Hermetically, Auxiliary Contacts
Mounting Type	Chassis Mount
Must Operate Voltage	9 VDC
Must Release Voltage	6 VDC
Operate Time	25 ms
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Release Time	12 ms
Switching Voltage [Max]	1000 VDC
Termination Style	Wire Leads, Stud

Part	Coil Voltage [Min]	Coil Voltage [Max]	Features	Switching Voltage [Max]	Contact Rating (Current)	Contact Form	Operate Time	Operating Temperature [Max]	Operating Temperature [Min]	Release Time	Termination Style	Must Operate Voltage	Must Release Voltage	Coil Current	Mounting Type
Altran Magnetics, LLC AEV250-MA	12 VDC	24 VDC	Auxiliary Contacts Economizer Sealed - Hermetically	1000 VDC	500 A	SPST-NO (DM) (1 Form X)	25 ms	85 °C	-40 °C	12 ms	Stud Wire Leads	9 VDC	6 VDC	130 mA	Chassis Mount
Altran Magnetics, LLC AEV250-M	12 VDC	24 VDC	Economizer Sealed - Hermetically	1000 VDC	500 A	SPST-NO (DM) (1 Form X)	25 ms	85 °C	-40 °C	12 ms	Stud Wire Leads	9 VDC	6 VDC	130 mA	Chassis Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	20	$ 78.40

General part information

DC CONTACTOR 500A 12-24VDC AUX
