94HBB08WRT

Active

Grayhill Inc.

SWITCH ROTARY DIP OCTAL 0.1A 50V

Search across all available documentation for this part.

Active

Grayhill Inc.

SWITCH ROTARY DIP OCTAL 0.1A 50V

Technical Specifications

Parameters and characteristics for this part

Part	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions	Current Rating (Amps)	Mounting Type	Actuator Type	Actuator Level	Length	Length	Features	Mechanical Life	Contact Finish	Height Above Board	Height Above Board	Pitch [x]	Pitch	Pitch [x]	Circuit	Body Material	Voltage Rating	Contact Material
Grayhill Inc. 94HBB08JT	J Lead	85 °C	-40 °C	8	100 mA	Surface Mount	Rotary with Shaft	Raised	0.39 "	9.91 mm	Sealed	10000 Steps	Gold	0.52 in	13.2 mm	0.1 in	Full	2.54 mm	Octal	Plastic	50 V	Copper Alloy
Grayhill Inc. 94HBB08WRT	Gull Wing	85 °C	-40 °C	8	100 mA	Surface Mount	Rotary with Shaft	Raised	0.39 "	9.91 mm	Sealed	10000 Steps	Gold	0.225 in	5.72 mm	0.1 in	Full	2.54 mm	Octal	Plastic	50 V	Copper Alloy
Grayhill Inc. 94HBB08WT	Gull Wing	85 °C	-40 °C	8	100 mA	Surface Mount	Rotary with Shaft	Raised	0.39 "	9.91 mm	Sealed	10000 Steps	Gold	0.225 in	5.72 mm	0.1 in	Full	2.54 mm	Octal	Plastic	50 V	Copper Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	150	$ 3.95

General part information

Dip Switch Octal 8 Position Surface Mount Rotary with Shaft Actuator 100mA 50VDC
