BH015-06-C-E

Active

GCT

CONN RECEPT SMD 6POS 3.96MM

Search across all available documentation for this part.

Active

GCT

CONN RECEPT SMD 6POS 3.96MM

Technical Specifications

Parameters and characteristics for this part

Specification	BH015-06-C-E

Connector Type	Receptacle, Bottom or Top Entry
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Female Socket
Current Rating (Amps)	7.9 A
Fastening Type	Push-Pull
Features	Pick and Place
Insulation Color	Black
Insulation Height [custom]	0.35 in
Insulation Height [custom]	8.89 mm
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Surface Mount
Number of Positions	6
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch - Mating	0.156 in
Pitch - Mating	3.96 mm
Termination	Solder

Part	Number of Positions	Contact Material	Number of Positions Loaded	Fastening Type	Contact Shape	Termination	Number of Rows	Mounting Type	Material Flammability Rating	Insulation Height [custom]	Insulation Height [custom]	Features	Contact Type	Contact Finish - Post	Current Rating (Amps)	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Material	Pitch - Mating	Pitch - Mating	Connector Type
GCT BH015-12-C-E	12	Phosphor Bronze	All	Push-Pull	Square	Solder	1	Surface Mount	UL94 V-0	0.35 in	8.89 mm	Pick and Place	Female Socket	Tin	7.9 A	Black	-40 °C	105 ░C	Liquid Crystal Polymer (LCP)	0.156 in	3.96 mm	Receptacle Bottom or Top Entry
GCT BH015-06-C-E	6	Phosphor Bronze	All	Push-Pull	Square	Solder	1	Surface Mount	UL94 V-0	0.35 in	8.89 mm	Pick and Place	Female Socket	Tin	7.9 A	Black	-40 °C	105 ░C	Liquid Crystal Polymer (LCP)	0.156 in	3.96 mm	Receptacle Bottom or Top Entry

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

6 Position Receptacle, Bottom or Top Entry Connector 0.156" (3.96mm) Surface Mount Tin
