M3902 BK002

Active

ALPHA WIRE

CABLE 2COND 10AWG BLACK 500'

Search across all available documentation for this part.

Active

ALPHA WIRE

CABLE 2COND 10AWG BLACK 500'

Technical Specifications

Parameters and characteristics for this part

Specification	M3902 BK002

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Bare
Conductor Strand	7 Strands, 0.0385 in
Jacket (Insulation) Diameter [diameter]	0.365 in
Jacket (Insulation) Diameter [diameter]	9.27 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	1.194 mm
Jacket (Insulation) Thickness	0.047 in
Jacket Color	Black
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	2
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-25 °C
Voltage	600 V
Wire Gauge	10 AWG

Part	Conductor Strand	Wire Gauge	Jacket (Insulation) Material	Length [x]	Length [x]	Conductor Material	Cable Type	Jacket Color	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Insulation	Voltage	Operating Temperature [Max]	Operating Temperature [Min]	Length	Length
ALPHA WIRE M3902 BK002	0.0385 in 7 Strands	10 AWG	Poly-Vinyl Chloride (PVC)	500 '	152.4 m	Copper Bare	Multi-Conductor	Black	0.365 in	9.27 mm	2	1.194 mm	0.047 in	Poly-Vinyl Chloride (PVC)	600 V	90 °C	-25 °C
ALPHA WIRE M3902 BK001	0.0385 in 7 Strands	10 AWG	Poly-Vinyl Chloride (PVC)			Copper Bare	Multi-Conductor	Black	0.365 in	9.27 mm	2	1.194 mm	0.047 in	Poly-Vinyl Chloride (PVC)	600 V	90 °C	-25 °C	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Conductor Multi-Conductor Cable Black 10 AWG 500.0' (152.4m)
