M1DXK-1036R

Active

3M (TC)

IDC CABLE - MKR10K/MC10M/X

Deep-Dive with AI

Search across all available documentation for this part.

Documents3302 Series Datasheet +1

M1DXK-1036R

Active

3M (TC)

IDC CABLE - MKR10K/MC10M/X

Deep-Dive with AI

Documents3302 Series Datasheet +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	M1DXK-1036R

Cable Termination	IDC
Color	Ribbon, Multiple
Connector Type	Socket to Cable
Contact Finish	Gold
Contact Finish Thickness	0.76 Ám
Contact Finish Thickness	30 Áin
Features	Polarizing Key, Strain Relief
Length [x]	3 ft
Length [x]	914.4 mm
Number of Positions	10
Number of Rows	2
Pitch - Cable	0.05 "
Pitch - Cable	1.27 mm
Pitch - Connector	0.1 in
Pitch - Connector	2.54 mm
Shielding	Unshielded

M1DXK Series

Part	Contact Finish Thickness	Contact Finish Thickness	Pitch - Connector	Pitch - Connector	Color	Contact Finish	Cable Termination	Shielding	Number of Rows	Pitch - Cable	Pitch - Cable	Connector Type	Number of Positions	Features	Length [x]	Length [x]
3M (TC) M1DXK-2036R	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Ribbon	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	20	Polarizing Key Strain Relief	3 ft	914.4 mm
3M (TC) M1DXK-4036R	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Ribbon	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	40	Polarizing Key Strain Relief	3 ft	914.4 mm
3M (TC) M1DXK-1036R	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Ribbon	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	10	Polarizing Key Strain Relief	3 ft	914.4 mm
3M (TC) M1DXK-3036J	0.76 Ám	30 Áin	0.1 in	2.54 mm		Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	30	Polarizing Key Strain Relief	3 ft	914.4 mm
3M (TC) M1DXK-2640K	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Twisted Pair (Flat)	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	26	Polarizing Key Strain Relief	3.34 ft	1.02 m
3M (TC) M1DXK-1436R	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Ribbon	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	14	Polarizing Key Strain Relief	3 ft	914.4 mm
3M (TC) M1DXK-4040K	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Twisted Pair (Flat)	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	40	Polarizing Key Strain Relief	3.34 ft	1.02 m
3M (TC) M1DXK-2040K	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Twisted Pair (Flat)	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	20	Polarizing Key Strain Relief	3.34 ft	1.02 m
3M (TC) M1DXK-6036R	0.76 Ám	30 Áin	0.1 in	2.54 mm	Multiple Ribbon	Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	60	Polarizing Key Strain Relief	3 ft	914.4 mm
3M (TC) M1DXK-2436J	0.76 Ám	30 Áin	0.1 in	2.54 mm		Gold	IDC	Unshielded	2	0.05 "	1.27 mm	Socket to Cable	24	Polarizing Key Strain Relief	3 ft	914.4 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 9.93
		10	$ 7.62
		25	$ 6.88
		50	$ 6.38
		100	$ 5.93
		250	$ 5.39
		500	$ 5.03
		1000	$ 4.71

Description

General part information

M1DXK Series

10 Position Cable Assembly Rectangular Socket to Cable 3.00' (914.40mm)
