4303-355-000-20
ActiveExcelitas Technologies
LED GREEN 1010 SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
4303-355-000-20
ActiveExcelitas Technologies
LED GREEN 1010 SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 4303-355-000-20 |
|---|---|
| Color | Green |
| Current - Test | 5 mA |
| Height (Max) [Max] [z] | 1 mm |
| Lens Style | Irregular |
| Millicandela Rating | 6.5 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 1010 (2525 Metric) |
| Size / Dimension [x] | 2.5 mm |
| Size / Dimension [y] | 2.5 mm |
| Supplier Device Package | 1010 |
| Voltage - Forward (Vf) (Typ) | 2.3 V |
| Wavelength - Peak | 575 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Strip | 1 | $ 15.00 | |
| 10 | $ 14.53 | |||
Description
General part information
4303-355 Series
Green LED Indication - Discrete 2.3V 1010 (2525 Metric)
