56310-503
ActiveLaird Thermal Systems, Inc.
PELTIER MOD CP10,127,06,L1,W4.5
Deep-Dive with AI
Search across all available documentation for this part.
56310-503
ActiveLaird Thermal Systems, Inc.
PELTIER MOD CP10,127,06,L1,W4.5
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 56310-503 |
|---|---|
| Current - Max [Max] | 3 A |
| Delta Tmax @ Th | 68 °C |
| Features | Lead Wires, Non-Sealed |
| Height [z] | 3.61 mm |
| Number of Stages | 1 |
| Operating Temperature | 80 °C |
| Qmax @ Th | 25.7 W |
| Resistance | 4.35 Ohms |
| Size / Dimension [x] | 29.72 mm |
| Size / Dimension [y] | 29.72 mm |
| Voltage - Max [Max] | 14.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 24.85 | |
| 5 | $ 23.45 | |||
| 10 | $ 22.74 | |||
| 25 | $ 22.04 | |||
| 50 | $ 21.48 | |||
| 100 | $ 20.92 | |||
Description
General part information
56310 Series
Peltier Module 25.7W @ 25°C 3 A 80°C
