LC20-02PMFS-SN8001

Active

Amphenol LTW

HEAVY DUTY SHIELDED SENSOR CONNECTOR, M20, METAL, 20A, 02 PINS, MALE CONNECTOR, FEMALE CONTACT, SQUARE, M20*1.0, SCREW THREAD, S

Search across all available documentation for this part.

Active

Amphenol LTW

HEAVY DUTY SHIELDED SENSOR CONNECTOR, M20, METAL, 20A, 02 PINS, MALE CONNECTOR, FEMALE CONTACT, SQUARE, M20*1.0, SCREW THREAD, S

Technical Specifications

Parameters and characteristics for this part

Part	Contact Finish - Mating	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Color	Mounting Feature	Shell Finish	Current Rating (Amps)	Connector Type	Number of Positions	Primary Material	Shell Size - Insert	Ingress Protection	Voltage Rating	Insert Material	Shell Material	Contact Material	Shielding
Amphenol LTW LC20-02PMFS-SN8001	Silver	Keyed	-40 °C	105 ░C	Silver	Flange	Nickel	20 A	Receptacle Female Sockets	2	Metal	M20-2	IP68 - Dust Tight Waterproof	300 VDC	Nylon Polyamide (PA)	Zinc Alloy	Copper Alloy	Shielded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Position Circular Connector Receptacle, Female Sockets Solder Cup
