MFM-05-15

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 15V 5W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

AC/DC CONVERTER 15V 5W

Technical Specifications

Parameters and characteristics for this part

Part	Number of Outputs	Type	Approval Agency	Efficiency	Current - Output (Max)	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input [Max]	Voltage - Input [Min]	Load Regulation	Package / Case	Applications	Voltage - Output 1	Line Regulation	Mounting Type	Current - Output (Max) [Max]
MEAN WELL USA Inc. MFM-05-15	1	Open Frame	CB CE cURus EAC TUV	81 %	330 mA	5 W	85 °C	-40 °C	264 VAC	80 VAC	0.5 %	4-DIP Module	Medical	15 V	0.3 %	Through Hole
MEAN WELL USA Inc. MFM-05-3.3	1	Open Frame	CB CE cURus EAC TUV	74 %		4.1 W	85 °C	-40 °C	264 VAC	80 VAC	0.5 %	4-DIP Module	Medical	3.3 V	0.3 %	Through Hole	1.25 A
MEAN WELL USA Inc. MFM-05-5	1	Open Frame	CB CE cURus EAC TUV	80 %		5 W	85 °C	-40 °C	264 VAC	80 VAC	0.5 %	4-DIP Module	Medical	5 V	0.3 %	Through Hole	1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Open Frame AC DC Converters 1 Output 15V 330mA 80 ~ 264 VAC Input
