LD35W-54-C0700-RD
ObsoleteEPtronics, Inc.
LED DRIVER AC/DC CC 18-54V 700MA
Deep-Dive with AI
Search across all available documentation for this part.
LD35W-54-C0700-RD
ObsoleteEPtronics, Inc.
LED DRIVER AC/DC CC 18-54V 700MA
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | LD35W-54-C0700-RD |
|---|---|
| Approval Agency | CE, FCC, cURus |
| Current - Output (Max) [Max] | 700 mA |
| Dimming | Analog, PWM |
| Efficiency | 85 % |
| Features | SCP, OCP, OVP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -30 ░C |
| Power (Watts) | 38 W |
| Ratings | IP65 |
| Size / Dimension [x] | 213.1 mm |
| Size / Dimension [x] | 8.39 in |
| Size / Dimension [y] | 26.7 mm |
| Size / Dimension [y] | 1.05 in |
| Size / Dimension [z] | 1.02 in |
| Size / Dimension [z] | 25.9 mm |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 277 VAC |
| Voltage - Input (Min) [Min] | 100 VAC |
| Voltage - Isolation | 3750 V |
| Voltage - Output [Max] | 54 V |
| Voltage - Output [Min] | 18 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
LD35W Series
700mA 18 ~ 54V Constant Current LED Driver AC DC Converter Topology 1 Output
