1SS416,L3M

Active

Toshiba Semiconductor and Storage

DIODE SCHOTTKY 30V 100MA SOD923

Search across all available documentation for this part.

Active

Toshiba Semiconductor and Storage

DIODE SCHOTTKY 30V 100MA SOD923

Technical Specifications

Parameters and characteristics for this part

Specification	1SS416,L3M

Capacitance @ Vr, F	15 pF
Current - Average Rectified (Io)	100 mA
Current - Reverse Leakage @ Vr	50 çA
Mounting Type	Surface Mount
Operating Temperature - Junction	125 °C
Package / Case	SOD-923
Speed	Any Speed
Speed	200 mA
Supplier Device Package	SOD-923
Technology	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	30 V
Voltage - Forward (Vf) (Max) @ If	500 mV

Part	Mounting Type	Package / Case	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max) [Max]	Operating Temperature - Junction	Technology	Supplier Device Package	Current - Average Rectified (Io)	Voltage - Forward (Vf) (Max) @ If	Capacitance @ Vr, F	Speed	Speed
Toshiba Semiconductor and Storage 1SS416,L3M	Surface Mount	SOD-923	50 çA	30 V	125 °C	Schottky	SOD-923	100 mA	500 mV	15 pF	Any Speed	200 mA
Toshiba Semiconductor and Storage 1SS416CT,L3F	Surface Mount	SOD-882	50 çA	30 V	125 °C	Schottky	CST2	100 mA	500 mV	15 pF	Any Speed	200 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Diode 30 V 100mA Surface Mount SOD-923
