Q-7100V0005024I

Active

Amphenol Custom Cable

CBL ASSY RPSMA-HDBNC JCK-PLG 24"

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-7100V0005024I

1st Connector	RP-SMA Jack
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	HD-BNC Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	RG-316
Color	Copper
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	3 GHz
Length	24 "
Length	609.6 mm
Overall Impedance	50 Ohms
Style	RP-SMA to HD-BNC

Q-7100V0 Series

Part	Cable Type	2nd Contact Gender	Style	Connector Impedance	1st Connector	2nd Connector	1st Contact Gender	Overall Impedance	2nd Connector Mounting Type	1st Connector Mounting Type	Features	Length	Length	Length	Frequency - Max [Max]	Color	Cable Impedance	Length [x]	Length [x]
Amphenol Custom Cable Q-7100V00031.5M	RG-174	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	59.1 in	4.9 ft	1.5 m	1 GHz	Black	50 Ohms
Amphenol Custom Cable Q-7100V00052.5M	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	98.4 in	8.2 '	2.5 m	3 GHz	Copper	50 Ohms
Amphenol Custom Cable Q-7100V0005006I	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	6 in		152.4 mm	3 GHz	Copper	50 Ohms
Amphenol Custom Cable Q-7100V0005024I	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	24 "		609.6 mm	3 GHz	Copper	50 Ohms
Amphenol Custom Cable Q-7100V0003108I	RG-174	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	108 in	9 ft	2.7 m	1 GHz	Black	50 Ohms
Amphenol Custom Cable Q-7100V0005018I	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded				3 GHz	Copper	50 Ohms	457.2 mm	457.2 mm
Amphenol Custom Cable Q-7100V0005060I	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	5 '	5 ft	1.5 m	3 GHz	Copper	50 Ohms
Amphenol Custom Cable Q-7100V00051.5M	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	59.1 in	4.9 ft	1.5 m	3 GHz	Copper	50 Ohms
Amphenol Custom Cable Q-7100V0005.75M	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	29.53 "		750 mm	3 GHz	Copper	50 Ohms
Amphenol Custom Cable Q-7100V0005036I	RG-316	Male	RP-SMA to HD-BNC	50 Ohms	RP-SMA Jack	HD-BNC Plug	Male	50 Ohms	Free Hanging (In-Line)	Free Hanging (In-Line)	Shielded	36 in		91.44 cm	3 GHz	Copper	50 Ohms

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 78.94
		25	$ 77.39
		50	$ 75.85
		100	$ 74.31
		250	$ 72.76

Description

General part information

Q-7100V0 Series

Cable Assembly Coaxial RP-SMA to HD-BNC RG-316 24.00" (609.60mm)
