ZUP60-3.5/LUW

Obsolete

TDK-LAMBDA

BENCH POWER SUPPLY, PROGRAMMABLE, 1 OUTPUT, 0 V, 60 V, 0 A, 3.5 A

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsZUP General Safety Inst

ZUP60-3.5/LUW

Obsolete

TDK-LAMBDA

BENCH POWER SUPPLY, PROGRAMMABLE, 1 OUTPUT, 0 V, 60 V, 0 A, 3.5 A

Deep-Dive with AI

DocumentsZUP General Safety Inst

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ZUP60-3.5/LUW

Accuracy - Voltmeter; Ammeter	0.02% + 35mV
Current - Output [Max]	3.5 A
Current - Output [Min]	0 A
Current Regulation - Line	2 mA
Current Regulation - Line	0.01 %
Current Regulation - Load	0.01 %, 5 mA
Display Type	Digital
Features	Memory, RS232 and RS485 Interface, Programmable
Number of Characters	3
Number of Outputs	1
Power (Watts)	200 W
Ripple	5 mV
Size / Dimension [x]	13.78 in
Size / Dimension [x]	350 mm
Size / Dimension [y]	124 mm
Size / Dimension [y]	4.882 in
Size / Dimension [z]	70 mm
Size / Dimension [z]	2.756 in
Type	Bench (AC to DC)
Voltage - Output [Max]	60 VDC
Voltage - Output [Min]	0 VDC
Voltage - Supply [Max]	265 VAC
Voltage - Supply [Min]	85 VAC
Voltage Regulation - Line	1 mV, 0.005 %
Voltage Regulation - Load	2 mV
Weight	6.4 lbs
Weight	2.9 kg

ZUP60 Series

Part	Accuracy - Voltmeter; Ammeter	Current Regulation - Load	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Ripple	Current - Output [Max]	Voltage - Output [Max]	Current Regulation - Line	Type	Number of Characters	Voltage Regulation - Line	Voltage - Supply [Max]	Voltage - Supply [Min]	Power (Watts)	Weight	Weight	Display Type	Voltage Regulation - Load	Number of Outputs	Features	Current Regulation - Line
TDK-LAMBDA ZUP60-14/LUW	0.02% + 35mV	0.07 % 10 mA	4.882 in	13.78 in	350 mm	5.512 in	124 mm	140 mm	5 mV	14 A	60 VDC	0.01 % 5 mA	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC	800 W	13 lbs	5.9 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface
TDK-LAMBDA ZUP60-3.5/LUW	0.02% + 35mV	0.01 % 5 mA	2.756 in	13.78 in	350 mm	4.882 in	70 mm	124 mm	5 mV	3.5 A	60 VDC	0.01 %	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC	200 W	6.4 lbs	2.9 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface	2 mA
TDK-LAMBDA ZUP60-7/U	0.02% + 35mV	0.01 % 5 mA	2.756 in	13.78 in	350 mm	4.882 in	70 mm	124 mm	5 mV	7 A	60 VDC	0.01 %	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC		7.1 lbs	3.2 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface	2 mA
TDK-LAMBDA ZUP60-3.5/U	0.02% + 35mV	0.01 % 5 mA	2.756 in	13.78 in	350 mm	4.882 in	70 mm	124 mm	5 mV	3.5 A	60 VDC	0.01 %	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC	200 W	6.4 lbs	2.9 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface	2 mA
TDK-LAMBDA ZUP60-14/U	0.02% + 35mV	0.07 % 10 mA	4.882 in	13.78 in	350 mm	5.512 in	124 mm	140 mm	5 mV	14 A	60 VDC	0.01 % 5 mA	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC	800 W	13 lbs	5.9 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface
TDK-LAMBDA ZUP60-14	0.02% + 35mV	0.07 % 10 mA	4.882 in	13.78 in	350 mm	5.512 in	124 mm	140 mm	5 mV	14 A	60 VDC	0.01 % 5 mA	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC	800 W	13 lbs	5.9 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface
TDK-LAMBDA ZUP60-14/LU	0.02% + 35mV	0.07 % 10 mA	4.882 in	13.78 in	350 mm	5.512 in	124 mm	140 mm	5 mV	14 A	60 VDC	0.01 % 5 mA	Bench (AC to DC)	3	0.005 % 1 mV	265 VAC	85 VAC	800 W	13 lbs	5.9 kg	Digital	2 mV	1	Memory Programmable RS232 and RS485 Interface

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Newark	Each	1	$ 1394.45
		10	$ 1324.72
		25	$ 1258.49
		50	$ 1258.49

Description

General part information

ZUP60 Series

ZUP60-3.5/LUW is a ZUP series Zero-up programmable DC power supply. It has built-in RS-232 & RS-485 Interface with IEEE488 (GPIB) optional.
