GB CSHPM1.13-HZKZ-35-0-350-R18
Activeams-OSRAM USA INC.
LED OSLON SSL150 BLUE 470NM 3SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
GB CSHPM1.13-HZKZ-35-0-350-R18
Activeams-OSRAM USA INC.
LED OSLON SSL150 BLUE 470NM 3SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | GB CSHPM1.13-HZKZ-35-0-350-R18 |
|---|---|
| Color | Blue |
| Current - Max [Max] | 1 A |
| Current - Test | 350 mA |
| Height - Seated (Max) | 1.54 mm |
| Height - Seated (Max) [Max] [z] | 0.061 in |
| Lumens/Watt @ Current - Test | 76 lm/W |
| Luminous Flux @ Current/Temperature [Max] | 112 lm |
| Luminous Flux @ Current/Temperature [Min] | 39 lm |
| Mounting Type | Surface Mount |
| Package / Case | 1212 |
| Package / Case | 3030 Metric |
| Size / Dimension [x] | 0.118 in |
| Size / Dimension [x] | 3 mm |
| Size / Dimension [y] | 3 mm |
| Size / Dimension [y] | 0.118 in |
| Supplier Device Package | 3-SMD |
| Thermal Resistance of Package [diameter] | 4.6 °C/W |
| Viewing Angle | 150 ° |
| Voltage - Forward (Vf) (Typ) | 2.85 V |
| Wavelength | 470 nm |
| Wavelength [Max] | 476 nm |
| Wavelength [Min] | 464 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.88 | |
| 10 | $ 1.19 | |||
| 100 | $ 0.88 | |||
| Digi-Reel® | 1 | $ 1.88 | ||
| 10 | $ 1.19 | |||
| 100 | $ 0.88 | |||
| Tape & Reel (TR) | 600 | $ 0.81 | ||
| 1200 | $ 0.67 | |||
| 3000 | $ 0.63 | |||
| 6000 | $ 0.62 | |||
| 15000 | $ 0.60 | |||
Description
General part information
GBCSHPM Series
LED Lighting Color OSLON® SSL 150 Blue 470nm (464nm ~ 476nm) 1212 (3030 Metric)
