AEDB-9340-B13C

Active

Broadcom Limited

ROTARY ENCODER OPTICAL 1000PPR

Search across all available documentation for this part.

Active

Broadcom Limited

ROTARY ENCODER OPTICAL 1000PPR

Technical Specifications

Parameters and characteristics for this part

Specification	AEDB-9340-B13C

Actuator Type	8 mm
Actuator Type	Open Center
Built in Switch	False
Detent	False
Encoder Type	Optical
Mounting Type	Chassis Mount, Motors
Output Type	Quadrature with Index (Incremental)
Pulses per Revolution	1000
Termination Style	Terminal Pins

Part	Termination Style	Output Type	Actuator Type	Actuator Type	Pulses per Revolution	Mounting Type	Encoder Type
Broadcom Limited AEDB-9340-W13A	Terminal Pins	Quadrature with Index (Incremental)	8 mm	Open Center	2500	Chassis Mount Motors	Optical
Broadcom Limited AEDB-9340-L13A	Terminal Pins	Quadrature with Index (Incremental)	8 mm	Open Center	1250	Chassis Mount Motors	Optical
Broadcom Limited AEDB-9340-B13C	Terminal Pins	Quadrature with Index (Incremental)	8 mm	Open Center	1000	Chassis Mount Motors	Optical
Broadcom Limited AEDB-9340-W14C	Terminal Pins	Quadrature with Index (Incremental)	5 mm	Open Center	2500	Chassis Mount Motors	Optical
Broadcom Limited AEDB-9340-T13A	Terminal Pins	Quadrature with Index (Incremental)	8 mm	Open Center	2000 pulses per revolution	Chassis Mount Motors	Optical
Broadcom Limited AEDB-9340-W06C	Terminal Pins	Quadrature with Index (Incremental)		1/4" Open Center	2500	Chassis Mount Motors	Optical
Broadcom Limited AEDB-9340-T13C	Terminal Pins	Quadrature with Index (Incremental)	8 mm	Open Center	2000 pulses per revolution	Chassis Mount Motors	Optical
