CFB700-48S28P
ActiveCincon Electronics Co. LTD
DC DC CONVERTER 28V 700W
Deep-Dive with AI
Search across all available documentation for this part.
CFB700-48S28P
ActiveCincon Electronics Co. LTD
DC DC CONVERTER 28V 700W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CFB700-48S28P |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Control Features | Active High, Enable |
| Current - Output (Max) [Max] | 25 A |
| Efficiency | 91 % |
| Features | Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Full Brick |
| Power (Watts) | 700 W |
| Size / Dimension [x] | 4.6 " |
| Size / Dimension [x] | 116.8 mm |
| Size / Dimension [y] | 2.4 " |
| Size / Dimension [y] | 61 mm |
| Size / Dimension [z] | 0.5 in |
| Size / Dimension [z] | 12.7 mm |
| Standard Number | 60950-1 |
| Supplier Device Package | Full Brick |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 75 V |
| Voltage - Input (Min) [Min] | 36 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 28 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 250.00 | |
Description
General part information
CFB700 Series
Isolated Module DC DC Converter 1 Output 28V 25A 36V - 75V Input
