AM40EW-11015SH30-NZ-K

Active

aimtec

DC DC CONVERTER 15V 40W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM40EW-11015SH30-NZ-K

Active

aimtec

DC DC CONVERTER 15V 40W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AM40EW-11015SH30-NZ-K

Applications	ITE (Commercial)
Approval Agency	CE
Current - Output (Max) [Max]	2.67 A
Efficiency	89 %
Features	Remote On/Off, Heat Sink
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	40 W
Size / Dimension [x]	51.4 mm
Size / Dimension [x]	2.02 in
Size / Dimension [y]	26.2 mm
Size / Dimension [y]	1.03 in
Size / Dimension [z]	16.5 mm
Size / Dimension [z]	0.65 in
Type	Isolated Module
Voltage - Input (Max) [Max]	160 V
Voltage - Input (Min) [Min]	40 V
Voltage - Isolation	3000 V
Voltage - Output 1	15 V

AM40E Series

Part	Efficiency	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Output 1	Approval Agency	Applications	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Type	Number of Outputs	Voltage - Isolation	Current - Output (Max) [Max]	Features	Voltage - Input (Max) [Max]	Power (Watts)	Mounting Type
aimtec AM40EW-11003SH30-NZ-K	85 %	16.5 mm	26.2 mm	51.4 mm	2.02 in	1.03 in	0.65 in	3.3 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	10 A	Heat Sink Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11003SH30-NZ	85 %	11.8 mm	25.4 mm	50.8 mm	2 in	25.4 mm	0.47 "	3.3 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	10 A	Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11015SH30-NZ-K	89 %	16.5 mm	26.2 mm	51.4 mm	2.02 in	1.03 in	0.65 in	15 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	2.67 A	Heat Sink Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11048SH30-NZ-K	87 %	16.5 mm	25.4 mm	50.8 mm	2 in	25.4 mm	0.65 in	48 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	830 mA	Heat Sink Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11048SH30-NZ	87 %	11.8 mm	25.4 mm	50.8 mm	2 in	25.4 mm	0.46 in	48 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	830 mA	Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11012SH30-NZ	89 %	11.8 mm	25.4 mm	50.8 mm	2 in	25.4 mm	0.47 "	12 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	3.33 A	Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11015SH30-NZ	89 %	11.8 mm	25.4 mm	50.8 mm	2 in	25.4 mm	0.47 "	15 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	2.67 A	Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11005SH30-NZ	86 %	11.8 mm	25.4 mm	50.8 mm	2 in	25.4 mm	0.47 "	5 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	8 A	Remote On/Off	160 V	40 W	Through Hole
aimtec AM40EW-11024SH30-NZ-K	87 %	16.5 mm	26.2 mm	51.4 mm	2.02 in	1.03 in	0.65 in	24 V	CE	ITE (Commercial)	40 V	85 °C	-40 °C	Isolated Module	1	3000 V	1.67 A	Heat Sink Remote On/Off	160 V	40 W	Through Hole

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 66.56
		5	$ 66.05
		10	$ 65.53
		19	$ 63.45
		38	$ 60.33
		57	$ 56.17
		76	$ 55.50

Description

General part information

AM40E Series

Isolated Module DC DC Converter 1 Output 15V 2.67A 40V - 160V Input
