MS27467T21B39SAL

Active

Souriau-Sunbank by Eaton

PLUG STRAIGHT CABLE

Search across all available documentation for this part.

Active

Souriau-Sunbank by Eaton

PLUG STRAIGHT CABLE

Technical Specifications

Parameters and characteristics for this part

Specification	MS27467T21B39SAL

Connector Type	Plug Housing
Contact Shape	Circular
Contact Size	16, 20
Contact Size	2, 37
Contact Type	Crimp
Fastening Type	Bayonet Lock
Features	Coupling Nut
Grade	Military
Housing Color	Olive Drab
Ingress Protection	IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	39
Operating Temperature [Max]	347 °F
Operating Temperature [Min]	-65 ░C
Orientation	A
Primary Material	Metal
Qualification	MIL-DTL-38999 Series I
Shell Finish	Cadmium
Shell Material	Aluminum Alloy
Shell Size - Insert [Max]	39
Shell Size - Insert [Min]	21
Shell Size, MIL	F
Shielding	Shielded
Type	For Female Sockets

Part	Connector Type	Current Rating (Amps)	Mounting Type	Color	Applications	Fastening Type	Shell Size - Insert [Min]	Shell Size - Insert [Max]	Number of Positions	Grade	Insert Material	Primary Material	Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shell Material	Ingress Protection	Termination	Shell Finish	Contact Finish - Mating	Qualification	Contact Material	Shielding	Features	Contact Size	Contact Size	Contact Type	Note	Shell Size, MIL	Housing Color	Type	Contact Shape	Material Flammability Rating	Shell Size - Insert	Number of Positions
Souriau-Sunbank by Eaton MS27467T21B39P	Male Pins Plug	7.5 A 13 A	Free Hanging (In-Line)	Olive Drab	Aviation Communication Systems Marine Medical Military	Bayonet Lock	21	39	39	Military	Thermoplastic	Metal	N	-65 ░C	347 °F	1.27 µm	50 µin	Aluminum Alloy	Environment Resistant	Crimp	Olive Drab Cadmium	Gold	MIL-DTL-38999 Series I	Copper Alloy	Shielded	Coupling Nut
Souriau-Sunbank by Eaton MS27467T21B39SAL	Plug Housing		Free Hanging (In-Line)			Bayonet Lock	21	39	39	Military	Thermoplastic	Metal	A	-65 ░C	347 °F			Aluminum Alloy	IP67		Cadmium		MIL-DTL-38999 Series I		Shielded	Coupling Nut	16 20	2 37	Crimp	Contacts Not Included	F	Olive Drab	For Female Sockets	Circular	UL94 V-0
Souriau-Sunbank by Eaton MS27467T21B16PAL	Plug Housing		Free Hanging (In-Line)			Bayonet Lock				Military	Thermoplastic	Metal	A	-65 ░C	347 °F			Aluminum Alloy	IP67		Cadmium		MIL-DTL-38999 Series I		Shielded	Coupling Nut	16		Crimp	Contacts Not Included	F	Olive Drab	For Male Pins	Circular	UL94 V-0	21-16	16

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

39 Position Circular Connector Plug Housing Free Hanging (In-Line) Coupling Nut
