GDLX-S-88K-50

Active

Kycon, Inc.

MODJK L/P RT< 8P8C P/S SHLD KEY

Search across all available documentation for this part.

Active

Kycon, Inc.

MODJK L/P RT< 8P8C P/S SHLD KEY

Technical Specifications

Parameters and characteristics for this part

Specification	GDLX-S-88K-50

Connector Type	Jack
Contact Finish	Gold
Contact Finish Thickness	50 µin
Contact Finish Thickness	1.27 µm
Contact Material	Phosphor Bronze
Features	Board Lock, Keyed
Housing Material	Polybutylene Terephthalate (PBT)
LED Color	Does Not Contain LED
Mounting Type	Through Hole
Number of Ports	1
Number of Positions/Contacts	8p8c (RJ45, Ethernet)
Number of Rows	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Orientation	90 °
Shielding	Shielded
Tab Direction	Down
Termination	Solder

Part	Number of Ports	Contact Material	Housing Material	Number of Positions/Contacts	Orientation	Connector Type	Contact Finish	Number of Rows	Operating Temperature [Max]	Operating Temperature [Min]	LED Color	Mounting Type	Contact Finish Thickness	Contact Finish Thickness	Tab Direction	Features	Shielding	Termination	Contact Finish Thickness
Kycon, Inc. GDLX-S-88K-50	1	Phosphor Bronze	Polybutylene Terephthalate (PBT)	8p8c (RJ45 Ethernet)	90 °	Jack	Gold	1	85 °C	-40 °C	Does Not Contain LED	Through Hole	50 µin	1.27 µm	Down	Board Lock Keyed	Shielded	Solder
Kycon, Inc. GDLX-N-64-50	1	Phosphor Bronze	Polybutylene Terephthalate (PBT)	6p4c	90 °	Jack	Gold	1	85 °C	-40 °C	Does Not Contain LED	Through Hole	50 µin	1.27 µm	Down		Unshielded	Solder
Kycon, Inc. GDLX-SMT-S-88	1	Phosphor Bronze	Thermoplastic	8p8c (RJ45 Ethernet)	90 °	Jack	Gold	1	85 °C	-40 °C	Does Not Contain LED	Surface Mount Right Angle Through Hole			Down	Board Lock Panel Stops	Shielded	Solder	Flash
Kycon, Inc. GDLX-SMT-A-64	1	Phosphor Bronze	Thermoplastic	6p4c	90 °	Jack	Gold	1	85 °C	-40 °C	Does Not Contain LED	Surface Mount			Down		Unshielded	Solder	Flash
Kycon, Inc. GDLX-N-88K-50	1	Phosphor Bronze	Polybutylene Terephthalate (PBT)	8p8c (RJ45 Ethernet)	90 °	Jack	Gold	1	85 °C	-40 °C	Does Not Contain LED	Through Hole	50 µin	1.27 µm	Down	Board Lock Keyed	Unshielded	Solder

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1140	$ 1.06
