AMEPR8D-1270AZ
Activeaimtec
AMEPR8D-1270AZ
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMEPR8D-1270AZ
Activeaimtec
AMEPR8D-1270AZ
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMEPR8D-1270AZ |
|---|---|
| Current - Output (Max) [Max] | 700 mA |
| Dimming | TRIAC |
| Efficiency | 78 % |
| Features | OCP, SCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 80 ¯C |
| Operating Temperature [Min] | -20 °C |
| Power (Watts) | 8.4 W |
| Ratings | IP67 |
| Size / Dimension [x] | 1.08 " |
| Size / Dimension [x] | 27.4 mm |
| Size / Dimension [y] | 2.77 in |
| Size / Dimension [y] | 70.3 mm |
| Size / Dimension [z] | 1.08 " |
| Size / Dimension [z] | 27.4 mm |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 264 VAC |
| Voltage - Input (Min) [Min] | 90 VAC |
| Voltage - Isolation | 3000 V |
| Voltage - Output [Max] | 12 V |
| Voltage - Output [Min] | 6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 2.45 | |
| 10 | $ 2.16 | |||
| 25 | $ 2.05 | |||
| 50 | $ 1.97 | |||
| 100 | $ 1.90 | |||
| 250 | $ 1.80 | |||
| 500 | $ 1.73 | |||
| 1000 | $ 1.67 | |||
| 5000 | $ 1.52 | |||
Description
General part information
AMEPR8D Series
700mA 6 ~ 12V Constant Current LED Driver AC DC Converter Topology 1 Output
